Features
• Multicolor display screen with a black background for contrast
• Backup audible alarm
• Multiple-language graphical user interface to support variety of users
• 96-hour trend memory with data captured every four seconds
• Distinctive digital signal processing technology
• Simple, intuitive operation with a space-saving design
• Displays plethysmographic waveforms, pulse amplitude and current measured SpO2 and pulse rate
Specifications
• SpO2: 1% to 100%
• Pulse rate: 20 to 250 beats per minute (bpm)
• Pulse amplitude: 0.03% to 20%
• Saturation: (% SpO2 ± 1 SD)
• Adult: 70% to 100% ± 2 digits
• Neonate: 70% to 100% ± 3 digits
• Low perfusion: 70% to 100% ± 2 digits
• Pulse rate: 20 to 250 bpm ± 3 digits
• Low perfusion: 20 to 250 bpm ± 3 digits
• Power requirements: 100 to 240 VAC, 50/60Hz, 45 VA
• Fuse rating: Fast-acting 2A 32VAC/DC, fast-acting 500mA 32VAC/50DC
• Type: Lithium ion
• Battery capacity: Minimum of five hours using new, fully charged battery with no alarms
• Instrument: 5°C to 40°C (41°F to 104°F)
• Transport/storage temperature (in shipping carton): -20°C to 60°C (-4°F to 140°F)
• Operating Humidity: 15% to 93% noncondensing
• Operating Altitude: -170 m to 4877 m (-557 ft to 16,000 ft)
• WEIGHT: 1.6 kg (3.5 lbs)
• Pulse: Amplitude indicator (eight segments)
• Visual indicators: Pulse search, audible alarms silenced or off, interference indicator, battery charging, SatSeconds alarm management clock, pleth
• Audible and visual alarms for high/low saturation and pulse rate
• SatSeconds alarm management settings: 10, 25, 50 and 100, or off
• Audible and visual warning indicators
• for low battery and sensor off
• Audible and visual sensor disconnect alarms
