Quick Reference
·
Vessel sealing system with Built in Surgical Diathermy Model: Fast seal" from Enertech, an excllent Economical , Hi performance Vessel sealing system used and appreciated by numerous hospitals. With local service availability, an Ideal Laproscopy surgery choice.
99 Programs Memory Display: Graphical LCD Display.
Dimension ( W x H x D ) : 300mm x 150 mm x 340 mm.
Weight : 5.5 kg.
Input Supply Voltage : 230 VAC + 15%@ 50/60Hz (110 V optional).
- Standard Vessel Sealing Cum Electrosurgical unit.
- Graphical LCD Display.
- 400w Power.
- Patient Plate Conductivity monitoring system.
Technical Specification
|
99 Programs Memory Interface
|
:
|
Graphical LCD Display.
|
|
Dimension (W x H x D)
|
:
|
300mm x 150 mm x 340 mm.
|
|
Weight
|
:
|
5.5 kg.
|
|
Input Supply Voltage
|
:
|
230 VAC + 15%@ 50/60Hz (110 V optional).
|
Monopolar Modes
Cut :
|
Mode
|
Max. Power Watt
|
Operating Frequency
|
|
Pure cut
|
400 W
|
480 khz
|
|
Blend 1
|
250 W
|
480 khz
|
|
Blend 2
|
200 W
|
480 khz
|
|
Endocut
|
99 W
|
480 khz
|
Coag :
|
Mode
|
Max. Power Watt
|
Operating Frequency
|
|
Spray
|
120 W
|
480 khz
|
|
Fulgurate
|
150 W
|
480 khz
|
|
Dessicate
|
150 W
|
480 khz
|
Bipolar Modes
|
Mode
|
Max. Power Watt
|
Operating Frequency
|
|
Bi-Coag
|
120 W
|
480 khz
|
|
Bi-Cut
|
120 W
|
480 khz
|
Sealer Modes
|
Mode
|
Max. Power Watt
|
Operating Frequency
|
|
Seal
|
150 W
|
480 khz
|
