Features
- NIBP button on the front panel, directly measuring the NIBP with pushing the button
- 72 hour data storage, 99 ID available, measurement record and trend review
- Bright, high resolution LCD screen displays the waveform as well as the SpO₂, PI* and PR readings
- Separate bright LEDs display for systolic, diastolic and mean Blood Pressure readings
Technical Specifications
Patient Range: Adult and pediatrics
SpO₂: Measurement range: 70%-100%
Pulse Rate: Measurement range: 30-250bpm
PI*: Measurement range: 0.2%-20%
NIBP: Method: Oscillometric
Operation Modes: Manual/Automatic/STAT
Measurement Unit: mmHg/kPa selectable
Measurement Types: Systolic, diastolic and mean
Data transmission: USB
Wired LAN (Optional)
Alarm: NIBP (SYS, DIA, MAP), SpO₂, PR, probe off, finger out, low voltage
Modes: Visible & 3-level audible alarms, error code
Storage: Patient ID: 1-99
Data Records: up to 72 hours
Appearance: Dimension: 296mm *175mm *96mm mm (±1mm)
Weight: 1.5±0.1kg
DisplayType: 2.8” LCD & LED screen
Parameters: NIBP(SYS, DIA, MAP) ,SpO₂, PI, PR, pulse bar, waveform
