Ideal for use: Operating Rooms, Veterinary Clinics, Ambulance / Mobile Clinics, Military Use, Disaster Management & Emergencies
· Ease of use and superior functionality
· Suitable for Adult and Pediatric patients
· Anti-Hypoxic guard
· Emergency oxygen flush
· Open to close changeover switch
· Fail proof audible indication of O supply pressure failure 2
· Automatic Nitrous Oxide shut off in the event of O failure 2
· Colour coded NIST inlets for piped medical gases
· Selectatec manifold mounting of Vaporiser
· Advanced Pediatric and Adult Ventilation with a choice of ventilators (optional)
· Multiple mounting possibilities
· Specially designed carry case
· Non-return / Pressure Relief Valve: Minimises risk of back flow of gases, blows off when pressure exceeds 125 CmH2O
· Oxygen Flush: Emergency oxygen flush switch at table level to give 35–70 Ltrs/min for emergencies
· O2 failure Warning Alarm: Self activated electro-pneumatic audio visual warning device to indicate drop in O2 pressure below 2.5 Bar
· Anti-Hypoxic Guard: Mixing device to proportion the N2O in such a way that minimum of 25% O2 is always delivered from the rotameter
· Common Gas Outlet (CGO): Conveniently located CGO with ISO tapers for 22mm & 15mm connections
· Basal Flow with On/off Switch: 250 ± 50 ml basal flow of Oxygen as soon as machine is switched on (optional)
· Pipe Line Gas Inlets: Non-Interchangeable Screw Threaded (NIST) pipeline inlets
· Pressure Gauges: Large diameter, color coded gauges fitted at convenient angle for better visibility and clarity.
· Selectatec Bracket: Single Selectatec Block
· Breathing Circuits: Bains Circuit
